3B Scientific Teltron Tube - Electron Diffraction

3B Scientific Teltron Tube - Electron Diffraction

B8A49566

Product code: B8A49566

Direct Delivery – up to 4 weeks.

Highly evacuated electron tube for demonstrating the wave nature of electrons through the observation of interference caused by passage of electrons through a polycrystalline graphite lattice (Debye-Scherrer diffraction) and rendered visible on a fluorescent screen. Also intended for determining the wavelength as a function of the anode voltage from the radii of the diffraction rings and the lattice plane spacing of graphite, as well as confirming de Broglie's hypothesis.

The tube uses an electron gun with an indirectly heated cathode to project a narrow converging beam of electrons through a thin layer of graphitised carbon supported on a fine mesh grid over the exit aperture of the gun. The cathode rays are diffracted in passing through the carbon layer and produce a ring pattern on the phosphor coated end of the tube. Study of the ring pattern and it's variation with different anode voltages permits the study and verification of the de Broglie's hypothesis, shows the dual nature of the electron, permits the calculation of the spacing of diffracting planes and suggests the probable arrangement of carbon atoms.

  • Operating instructions supplied.

Technical Specifications:

  • Maximum filament voltage: = 7.5V AC/DC
  • Maximum anode voltage: 5 kV
  • Anode current: 0.15mA at 4kV
  • Lattice constant of graphite: d10 = 0.213 nm; d11 = 0.123 nm

Requires the following products to operate:

  • B8A49463 - Universal Stand
  • B8R02653 - EHT Power Supply - to power the anode
  • B8R05926 - Black Safety Lead - for EHT Connection
  • B8R05927 - Red Safety Lead - for EHT Connection
  • PP00051016 - 2mm Adaptor Lead
  • B8G85458 - Bench Power Supply - to power the filament
  • Stackable 4mm Plug Leads (black)
  • Stackable 4mm Plug Leads (red)
  • A-Level Physics: Atomic Physics (de Broglie hypothesis)

Further Information

Age Recommended from
16 Years
Anode Current
0.15mA at 4kV
Brand
UK 3B Scientific
Curriculum Link
Atomic Physics
Key Stage Suitability
Key Stage 5+
Lattice Constant of Graphite
d10 = 0.213 nm; d11 = 0.123 nm
Maximum Anode Voltage
5 kV
Maximum Filament Voltage
Less than or equal to 7.5V AC/DC
Product Type
Teltron Tube

Documents
